Dimensions
Ground Clearance	1.1 ft ( 0 m )
Height - Top of Cab	10.0 ft ( 3 m )
Length of Track on Ground	8.1 ft ( 2 m )
Width Over Tracks	9.2 ft ( 3 m )
Engine
Displacement	360.1 cu in ( 5,901 cu cm )
Engine Model	6T-590
Gross Power	124.0 hp ( 92 kw )
Max Torque	372.0 lbs ft ( 504 nm )
Net Power	119.0 hp ( 89 kw )
Number of Cylinders	6.0
Power Measured @	2,000.0 rpm
Torque Measured @	1,600.0 rpm
Hydraulic System
Pump Flow Capacity	33.3 gpm ( 126 lpm )
Relief Valve Pressure	2,500.0 psi
Operating Specifications
Alternator Supplied Amperage	45 amps
Cooling System Fluid Capacity	6.5 gal ( 25 l )
Engine Oil Capacity	4.0 gal ( 15 l )
Final Drives Fluid Capacity	2.1 gal ( 8 l )
Fuel Capacity	56.1 gal ( 212 l )
Hydraulic Fluid Capacity	17.0 gal ( 64 l )
Operating Voltage	12.0 volts
Transmission
Max Speed - Forward	5.8 mph ( 9 kph )
Max Speed - Reverse	6.9 mph ( 11 kph )
Number of Forward Gears	4.0
Number of Reverse Gears	4.0
Undercarriage
Ground Contact Area	3,868.0 cu in ( 63,385 cu cm )
Ground Pressure	6.5 psi
Number of Carrier Rollers per Side	2.0
Number of Shoes per Side	43.0
Number of Track Rollers per Side	7.0
Standard Shoe Size	508.0 in ( 1,290 cm )
Track Gauge	5.2 ft ( 2 m )
