For Sale: $44,000.00 USD
Apply for FinancingSerial Number: | 349030119 |
Stock Number: | C98798 |
Machine Location: | SUN PRAIRIE, WI |
Supplied by HeavyEquipmentData.com →
Bucket | |
Breakout Force | 6,294.6 lbs ( 2,855 kg ) |
Bucket Width | 5.5 ft ( 2 m ) |
Tipping load Standard bucket | 4,761.9 lbs ( 2,160 kg ) |
Dimensions | |
Ground Clearance | 0.9 ft ( 0 m ) |
Height - Top of Cab | 7.9 ft ( 2 m ) |
Hinge Pin - Max Height | 10.0 ft ( 3 m ) |
Length with Bucket on Ground | 16.3 ft ( 5 m ) |
Reach at Max Lift and Dump | 1.0 ft ( 0 m ) |
Wheelbase | 6.1 ft ( 2 m ) |
Width Over Tires | 5.3 ft ( 2 m ) |
Engine | |
Displacement | 133.6 cu in ( 2,189 cu cm ) |
Engine Make | Yanmar |
Net Power | 47.0 hp ( 35 kw ) |
General Specifications | |
?Model | 5,055.0 |
Bucket Capacity cu. yd. (cu m) | 0.72 (.55) |
Category | Wheel Loaders |
Engine Power hp (kw) | 46 (34) |
Engine type | Yanmar 4NNKAC |
Max Dump Height ft. (m) | 7.6 (2.31) |
Operating?Weight | 7,936 (3,600) |
Hydraulic System | |
Pump Flow Capacity | 22.2 gpm ( 84 lpm ) |
Relief Valve Setting | 3,481.0 psi |
Operating Specifications | |
Alternator Supplied Amperage | 55 amps |
Fuel Capacity | 15.6 gal ( 59 l ) |
Hydraulic System Fluid Capacity | 61.3 gal ( 232 l ) |
Operating Voltage | 12.0 volts |
Operating Weight | 7,936.6 lbs ( 3,600 kg ) |
Payload | 3,527.4 lbs ( 1,600 kg ) |
Tire Size | 10.5-18 |
Transmission | |
Travel Speed | 12.4 mph ( 20 kph ) |
